Jet Black
Add to Wish List
Item:
V-169
Inventory:
In Stock
Description:
- Suitable Substrates: All ferrous and non-ferrous metals.
- All V Series coatings are one-part, ready to spray.
- V Series coatings are an industrial performance product. Gloss may vary upon application.
Cerakote V Series ceramic coatings are the unrivaled leader in high temperature thin film performance coatings, capable of temperatures up to 1800°F. V Series coatings provide unmatched high temperature performance, while providing excellent chemical resistance, durability and aesthetics. The foundation for Cerakote V Series coatings is a unique inorganic ceramic technology that imparts both high temperature performance and excellent physical stability. Due to the inorganic chemistry, V-Series coatings are UV Stable. For more information, see our Technical Data Sheet (TDS). *NOTE: This product does not require catalyst. This color does require a 150 Mesh Strainer (SE-276).
WARNING: This product may expose you to chemicals known to the State of California to cause cancer. For more information, see the product's safety data sheet.
Product Technical Data:
All results based on blasted steel coated at recommended mil thickness using recommended cure schedule.
*Gloss levels are measured at a 60° angle. Adjustments to recommended conditions will yield different results. Gloss is affected by quality of preparation and spray technique. Results are based on coated blasted steel cured following the Cure Schedule specification.
**Viscosity measured under ambient conditions (air temperature, relative humidity) at the time of manufacture.
¶Recommended Cure Temperature:
- Please reference the Cure Schedule specification available on each Cerakote product.
Maximum Temperature is the temperature to which the color or coating is stable.
‡Chemical Resistance Testing: Results refer to color change based on CIE76 formulation. Results range from:
- Excellent: ∆E change of <2.5
- Good: ∆E change of <3.0
- Fair: ∆E change of <3.5
- Poor: ∆E change of <4.0
†Testing parameters are as follows:
- Hardness or Pencil Hardness Tests are measured from softest to hardest as follows: 9B, 8B, 7B, 6B, 5B, 4B, 3B, 2B, B, HB, F, H, 2H, 3H, 4H, 5H, 6H, 7H, 8H, 9H. 9H is the hardest.
- SG-100 ONLY: Hardness test Method A — An X-cut is made through the film to the substrate, pressure-sensitive tape is applied over the cut and then removed, and adhesion is assessed qualitatively on a 0 to 5 scale.
- Adhesion is measured on a scale of 0B, 1B, 2B, 3B, 4B, 5B, with 5B being the highest achievable rating.
- Flexibility or Conical Mandrel Bend: “100% Resistance” is the highest achievable rating and indicates that the coating did not crack or spall.
- Impact Performance (Direct/Indirect) is measured on a scale of 0 inch-lbs. to 160 inch-lbs., with 160 inch-lbs. being the highest achievable rating.
All Cerakote coatings are VOC compliant under the EPA and have low to no VOC content. To find out the VOC content of an individual coating, please contact sds@nicindustries.com for more information.
This information is accurate to the best of our knowledge, however, it shall not constitute a guarantee for any specific product features and shall not establish a legally valid contractual relationship. We recommend that you perform adequate tests in your facility to determine if this product meets all of your requirements.
Please feel free to email us at info@cerakote.com or call us at 1-866-774-7628 if you have any questions.
